The simplest solution among the vehicle interfaces offered by TEXA.
Small, robust, lightweight and ergonomic, it has been specifically developed for the diagnostic operations in the CAR environment.
Every aspect of NAVIGATOR NANO S 2 has been carefully designed and developed to fully satisfy the needs of the modern workshops, creating an interface that is rich in innovative technical details.
Just think of its new latest-generation processor, 8 GB storage, and an advanced connectivity that includes a Bluetooth 5.0 module.
Moreover, NAVIGATOR NANO S 2 is compatible with the CAN FD, supporting the simultaneous management of the 3 channels, and DoIP communication protocols.
Customer Service
Team and technology at your service
* Verify the availability of SERVICER in your own country.
Technical features
Processor: CORTEX M7 STM32H735AGI6 up to 550
MHz, 1MB FLASH, 564KB RAM
SRAM: 16 MBits organized in 1024K x 16 bits
eMMC: 8 GByte on an 8-bit bus
External Flash memory: 16 Mbit flash NOR organized as 1M x 16bit
Internal battery:
Lithium polymer, single cell
3.7 V 130 mA/h
LP401429-PCM-LD
Vehicle Battery: 12 Vdc system management
Nominal power supply voltage: OBD: 12 V direct voltage
Wireless communication: Bluetooth 5.0 class1
Operating frequency band: 2402 … 2480 MHz
Maximum radio frequency power transmitted: 10 dBm
Wired connection:
• Virtual COM Via USB Full Speed
• USB C: 5 V *
Electronic switch: 2-way, 13 independent positions
Diagnostic connector: OBD
Supported protocols:
• Blink codes
• K, L (with 60 mA current protection) ISO9141-2, ISO14230
• CAN_FD 11898-2:2016 3 channels
• CAN ISO 11898-3
• CAN SAE J2411 Single Wire
• SAE J1850 PWM e VPW
• Ethernet DoIP ISO13400-3
Power supply connector: OBD
User interface:
• LED RGB x4
• Buzzer
Consumption: 12 V direct voltage , 250 mA
Operating temperature: 0 °C … 40 °C
Storing temperature: -20 °C … 60 °C
Battery charging temperature: 0 °C … 45 °C
Operating moisture: 10% … 80% without condensation
Weight: 72 g
Environmental conditions:
• Use: internal and external
• Altitude: < 2000 m
• Supply voltage fluctuations: ±10%
• Overvoltage category: II
• Pollution degree: 2
• Maximum relative humidity 80% for temperatures up to 31 °C, linearly decreasing to 50% at 40 °C
Directives:
RED 2014/53/EU
RoHS 2011/65/EU and delegated Directive
2015/863/EU
Regulations:
Radio Equipment Regulation 2017 No. 1206
RoHS Regulation 2012 No. 3032
Electromagnetic compatibility:
ETSI EN 301 489-1
ETSI EN 301 489-17
Radio systems: ETSI EN 300 328
Electrical safety:
EN 62368-1
EN 62368-3
EN 62311
